RD-125-1224
Manufacturer MEAN WELL

RD-125-1224

Availability: Out of stock

Request a Backorder

Submit your request and we will confirm lead time.

RD-125-1224
Quantity Prices (CAD)
Quantity
Unit Price (CAD)
1+
$42.60 CAD
10+
$40.47 CAD
20+
$39.62 CAD
50+
$38.77 CAD
100+
$37.91 CAD
200+
$37.06 CAD
All prices are displayed in CAD. *Import tariff is included in the listed price. You pay exactly what you see—no surprise fees at checkout. Discounts are applied automatically based on the total quantity added to your cart.
Quick Specs
Input Voltage
88V-264V
Output Voltage
12 / 24V
Rated Current
7 / 5A
Power Rating
133.2W
Waterproof
Non-waterproof
Dimensions & Weight
7.83 x 3.86 x 1.5 in

Datasheet (PDF)

Open PDF
If the PDF doesn’t load here, click “Open PDF”.

The MEAN WELL RD-125-1224 is a 133.2W dual-output enclosed power supply providing 12V and 24V from a single unit. It is designed for industrial control, instrumentation, telecom and other equipment that needs two DC rails from one supply.

Key features

  • CH1: 12V, 3.7A rated (0–7A)
  • CH2: 24V, 3.7A rated (0–5A)
  • Input: 88–132VAC / 176–264VAC (selected by switch), 248–373VDC
  • Protections: overload, over voltage
  • Typical efficiency 85%

Specifications

Output Voltage Rated current Current range Ripple & noise (max.)
CH1 12V 3.7A 0–7A 120mVp-p
CH2 24V 3.7A 0–5A 200mVp-p
Model RD-125-1224
Series RD-125
Total rated power 133.2W
Voltage adjustment CH1: 11.4–13.2V
Input 88–132VAC / 176–264VAC (selected by switch), 248–373VDC
Efficiency (typ.) 85%
Working temperature -25 to +70°C (-13 to 158°F) ambient, derating per datasheet curve
Dimensions 199 × 98 × 38 mm (7.83 × 3.86 × 1.50 in) (L × W × H)
Weight 0.59 kg

Typical applications: industrial control, instrumentation, telecom and other equipment that needs two DC rails from one supply.

Datasheet: RD-125 series specification (PDF). Ships from Miami, FL.

Similar Models

Same product family and output voltage, with the closest available power ratings.

Environmental Documents
📄 E6) COC-REACH (2026/01/28) 📄 E9) CMRT (2025/04/25) 📄 E14) COC-ROHS 2 (2015/863/EU) (2024/10/04) 📄 REACH Certificate (PDF) (2020/12/03) 📄 ROHS Certificate (PDF) (2020/05/29) 📄 E12) COC-ROHS 2 (2011/65/EU) (2016/10/01)
