DDR-120C-12
Manufacturer MEAN WELL

DDR-120C-12

Availability: Out of stock

Request a Backorder

Submit your request and we will confirm lead time.

DDR-120C-12
Quantity Prices (CAD)
Quantity
Unit Price (CAD)
1+
$91.74 CAD
10+
$87.15 CAD
20+
$85.32 CAD
50+
$83.48 CAD
100+
$81.65 CAD
200+
$79.81 CAD
All prices are displayed in CAD. *Import tariff is included in the listed price. You pay exactly what you see—no surprise fees at checkout. Discounts are applied automatically based on the total quantity added to your cart.
Quick Specs
Input Voltage
33.6V-67.2V DC
Output Voltage
12V
Rated Current
10A
Power Rating
120W
Waterproof
Non-waterproof
Dimensions & Weight
1.26 x 4.93 x 4.02 in

Datasheet (PDF)

Open PDF
If the PDF doesn’t load here, click “Open PDF”.

The MEAN WELL DDR-120C-12 is a DIN rail DC-DC converter delivering 12V at up to 10A (120W rated). It is designed for industrial control, transportation, battery-powered and solar systems and other DC-bus applications.

Key features

  • Output: 12V, 10A rated
  • Input: 33.6–67.2VDC
  • Protections: overload, over voltage
  • Typical efficiency 89.5%

Specifications

Model DDR-120C-12
Series DDR-120C
Output 12V / 10A
Rated power 120W
Input 33.6–67.2VDC
Efficiency (typ.) 89.5%
Working temperature -40 to +70°C (-40 to 158°F)
Dimensions 32 × 125.2 × 102 mm (1.26 × 4.93 × 4.02 in)

Typical applications: industrial control, transportation, battery-powered and solar systems and other DC-bus applications.

Datasheet: DDR-120C series specification (PDF). Ships from Miami, FL.

Similar Models

Same product family and output voltage, with the closest available power ratings.

Environmental Documents
📄 E6) COC-REACH (2026/01/28) 📄 E9) CMRT (2025/04/25) 📄 E14) COC-ROHS 2 (2015/863/EU) (2024/10/04) 📄 REACH Certificate (PDF) (2020/12/03) 📄 ROHS Certificate (PDF) (2020/05/29) 📄 E12) COC-ROHS 2 (2011/65/EU) (2016/10/01)
