GST160A36-R7B
Manufacturer MEAN WELL

TPS160A36-R7B

Availability: Out of stock

Request a Backorder

Submit your request and we will confirm lead time.

TPS160A36-R7B
Quantity Prices (CAD)
Quantity
Unit Price (CAD)
1+
$79.60 CAD
10+
$75.62 CAD
20+
$74.03 CAD
50+
$72.44 CAD
100+
$70.84 CAD
200+
$69.25 CAD
All prices are displayed in CAD. *Import tariff is included in the listed price. You pay exactly what you see—no surprise fees at checkout. Discounts are applied automatically based on the total quantity added to your cart.
Quick Specs
Input Voltage
85V-264V
Output Voltage
36V
Rated Current
4.44A
Power Rating
160W
Waterproof
Non-waterproof
Dimensions & Weight
6.89 x 2.83 x 1.38 in

Datasheet (PDF)

Open PDF
If the PDF doesn’t load here, click “Open PDF”.

The MEAN WELL GST160A36-R7B is a AC/DC adapter delivering 36V at up to 4.44A (160W rated). It is designed for consumer and industrial electronics, telecom and networking equipment, test instruments and other devices that need an external DC supply.

Key features

  • Output: 36V, 4.44A rated
  • Input: 85–264VAC / 120–370VDC
  • Protections: overload, over voltage, over temperature
  • Typical efficiency 92%

Specifications

Model GST160A36-R7B
Series GST160A
Output 36V / 4.44A
Rated power 160W
Input 85–264VAC / 120–370VDC
Efficiency (typ.) 92%
Working temperature -30 to +70°C (-22 to 158°F)
Dimensions 175 × 72 × 35 mm (6.89 × 2.83 × 1.38 in)
Weight 0.66 kg

Typical applications: consumer and industrial electronics, telecom and networking equipment, test instruments and other devices that need an external DC supply.

Datasheet: GST160A series specification (PDF). Ships from Miami, FL.

Similar Models

Same product family and output voltage, with the closest available power ratings.

Environmental Documents
📄 E6) COC-REACH (2026/01/28) 📄 E9) CMRT (2025/04/25) 📄 E14) COC-ROHS 2 (2015/863/EU) (2024/10/04) 📄 REACH Certificate (PDF) (2020/12/03) 📄 ROHS Certificate (PDF) (2020/05/29) 📄 E12) COC-ROHS 2 (2011/65/EU) (2016/10/01)
