XLG-150-H-DA2
Manufacturer MEAN WELL

XLG-150-H-DA2

Availability: 2 can ship immediately

Request a Backorder

Submit your request and we will confirm lead time.

XLG-150-H-DA2 SKU: 025-08749
Quantity
Quantity Prices (CAD)
Quantity
Unit Price (CAD)
1+
$109.76 CAD
10+
$104.27 CAD
20+
$102.08 CAD
50+
$99.88 CAD
100+
$97.69 CAD
200+
$95.49 CAD
All prices are displayed in CAD. *Import tariff is included in the listed price. You pay exactly what you see—no surprise fees at checkout. Discounts are applied automatically based on the total quantity added to your cart.
Quick Specs
Input Voltage
100V-305V
Output Voltage
27-56V
Rated Current
1.4-4.17A
Power Rating
150W
Waterproof
IP67
Dimensions & Weight
7.09 x 2.48 x 1.4 in

Datasheet (PDF)

Open PDF
If the PDF doesn’t load here, click “Open PDF”.

The MEAN WELL XLG-150-H-DA2 is a 150W constant power mode LED driver with a 27–56V constant current region and a 2800mA default output current (full power at 2680–4170mA). It is designed for LED street, area and flood lighting, high-bay fixtures, signage, architectural and other indoor or outdoor LED installations.

Key features

  • Output: 2800mA default, constant current region 27–56V
  • Input: 100–305VAC / 142–431VDC
  • IP67 rated housing
  • DALI-2 interface (IEC 62386-101, 102, 207, 251, DT6)
  • Protections: short circuit, over voltage, over temperature
  • Typical efficiency 92%
  • 5-year manufacturer warranty

Specifications

Model XLG-150-H-DA2
Series XLG-150-DA2
Output 2800mA default, 27–56V
Rated power 150W
Input 100–305VAC / 142–431VDC
Efficiency (typ.) 92%
Protection rating IP67
Working temperature Tcase -40 to +90°C (-40 to 194°F)
Dimensions 180 × 63 × 35.5 mm (7.09 × 2.48 × 1.40 in)
Weight 0.8 kg

Typical applications: LED street, area and flood lighting, high-bay fixtures, signage, architectural and other indoor or outdoor LED installations.

Datasheet: XLG-150-DA2 series specification (PDF). Ships from Miami, FL.

SKU: 025-08749

Similar Models

Same product family and output voltage, with the closest available power ratings.

Environmental Documents
📄 E6) COC-REACH (2026/01/28) 📄 E9) CMRT (2025/04/25) 📄 E14) COC-ROHS 2 (2015/863/EU) (2024/10/04) 📄 REACH Certificate (PDF) (2020/12/03) 📄 ROHS Certificate (PDF) (2020/05/29) 📄 E12) COC-ROHS 2 (2011/65/EU) (2016/10/01)
