XLG-240-48-ABV
Manufacturer MEAN WELL

XLG-240-48-ABV

Availability: Out of stock

Request a Backorder

Submit your request and we will confirm lead time.

XLG-240-48-ABV SKU: 025-149
560 units available on request

Ready to ship in 1–2 business days. Please contact customer service to request this item. Requests are confirmed by our team before payment.

Contact customer service
Quantity Prices (CAD)
Quantity
Unit Price (CAD)
1+
$62.98 CAD
10+
$59.83 CAD
20+
$58.57 CAD
50+
$57.31 CAD
100+
$56.05 CAD
200+
$54.79 CAD
All prices are displayed in CAD. *Import tariff is included in the listed price. You pay exactly what you see—no surprise fees at checkout. Discounts are applied automatically based on the total quantity added to your cart.
Quick Specs
Input Voltage
100V-305V
Output Voltage
43.2-52.8V
Rated Current
5A
Power Rating
240W
Waterproof
IP67
Dimensions & Weight
8.62 x 2.48 x 1.4 in

Datasheet (PDF)

Open PDF
If the PDF doesn’t load here, click “Open PDF”.

The MEAN WELL XLG-240-48-ABV is a constant voltage LED driver delivering 48V at up to 5A (240W rated). It is designed for LED street, area and flood lighting, high-bay fixtures, signage, architectural and other indoor or outdoor LED installations.

Key features

  • Output: 48V, 5A rated
  • Input: 110–305VAC / 156–431VDC
  • IP67 rated housing
  • Output voltage adjustable 43.2–52.8V
  • 3-in-1 dimming (ABV-Type)
  • Protections: short circuit, overload, over voltage, over temperature
  • Typical efficiency 91%
  • 5-year manufacturer warranty

Specifications

Model XLG-240-48-ABV
Series XLG-240
Output 48V / 5A
Rated power 240W
Input 110–305VAC / 156–431VDC
Efficiency (typ.) 91%
Protection rating IP67
Working temperature Tcase -20 to +90°C (-4 to 194°F)
Dimensions 219 × 63 × 35.5 mm (8.62 × 2.48 × 1.40 in)
Weight 1 kg

Typical applications: LED street, area and flood lighting, high-bay fixtures, signage, architectural and other indoor or outdoor LED installations.

Datasheet: XLG-240 series specification (PDF). Ships from Miami, FL.

SKU: 025-149

Similar Models

Same product family and output voltage, with the closest available power ratings.

Environmental Documents
📄 E6) COC-REACH (2026/01/28) 📄 E9) CMRT (2025/04/25) 📄 E14) COC-ROHS 2 (2015/863/EU) (2024/10/04) 📄 REACH Certificate (PDF) (2020/12/03) 📄 ROHS Certificate (PDF) (2020/05/29) 📄 E12) COC-ROHS 2 (2011/65/EU) (2016/10/01)
