HVGC-480-L-AB MEAN WELL Power Supply | HTD Electronics
Manufacturer MEAN WELL

HVGC-480-L-AB

Availability: Out of stock
480 W350 V1.4 AIP65180V–528V in

Request a Backorder

Submit your request and we will confirm lead time.

HVGC-480-L-AB
Quantity Prices (CAD)
Quantity
Unit Price (CAD)
1+
$252.90 CAD
10+
$240.26 CAD
20+
$235.20 CAD
50+
$230.14 CAD
100+
$225.08 CAD
200+
$220.02 CAD
All prices are displayed in CAD. *Import tariff is included in the listed price. You pay exactly what you see—no surprise fees at checkout. Discounts are applied automatically based on the total quantity added to your cart.
Quick Specs
Input Voltage
180V~528V
Output Voltage
350V
Rated Current
1.4A
Power Rating
480W
Waterproof
IP65
Dimensions & Weight
10.31 x 4.92 x 1.72 in5.99 lbs

Datasheet (PDF)

Open PDF
If the PDF doesn’t load here, click “Open PDF”.

Features

Wide input range 180 ~ 528VAC
Constant Current mode output
Metal housing with Class I design
Built-in active PFC function
Function options: output adjustable via potentiometer; 3 in 1 dimming (dim-to-off) ; Timer dimming
Typical lifetime>50000 hours
5 years warranty

General Specification

AC input voltage range 180~528VAC | 254VDC ~ 747VDC
AC inrush current (max.) COLD START 40A(t =1250 s measured at 50% I ) at 480VAC; width peak Per NEMA 410
Over temperature protection Shut down output voltage, re-power on to recovery
Over-voltage protection Up to 108% Shut down o/p voltage with auto-recovery or re-power on to recovery
Withstand voltage I/P-O/P:3.75KVAC I/P-FG:2KVAC O/P-FG:1.5KVAC
Working temperature -40~+90ºC (refer to output derating curve)
Safety standards UL8750(type” HL”), CAN/CSA C22.2 NO. 250. 13-17, ; ENEC BS EN/EN61347-1, BS EN/EN61347-2-13 independent, BS EN/EN62384 CCC GB19510.1,GB19510.14 EAC TP TC 004, IP67 approved
EMC standards Compliance to EN61000-4-2,3,4,5,6,8,11, EN61547, light industry level(surge immunity Line-Earth 4KV,Line-Line 2KV), criteria A
Dimension (LxWxH)(mm) 262 x 125 x 43.8 mm

Similar Models

Same product family and output voltage, with the closest available power ratings.

Environmental Documents
📄 E6) COC-REACH (2026/01/28) 📄 E9) CMRT (2025/04/25) 📄 E14) COC-ROHS 2 (2015/863/EU) (2024/10/04) 📄 REACH Certificate (PDF) (2020/12/03) 📄 ROHS Certificate (PDF) (2020/05/29) 📄 E12) COC-ROHS 2 (2011/65/EU) (2016/10/01)
