EPS-45-15-C MEAN WELL Power Supply | HTD Electronics
Manufacturer MEAN WELL

EPS-45-15-C

Availability: Out of stock
45 W15 V3 A90Vā€“264V in

Request a Backorder

Submit your request and we will confirm lead time.

EPS-45-15-C
Quantity Prices (CAD)
Quantity
Unit Price (CAD)
1+
$25.98 CAD
10+
$24.68 CAD
20+
$24.16 CAD
50+
$23.64 CAD
100+
$23.12 CAD
200+
$22.60 CAD
All prices are displayed in CAD. *Import tariff is included in the listed price. You pay exactly what you seeā€”no surprise fees at checkout. Discounts are applied automatically based on the total quantity added to your cart.
Quick Specs
Input Voltage
90V~264V
Output Voltage
15V
Rated Current
3A
Power Rating
45W
Waterproof
Non-waterproof
Dimensions & Weight
4.07 x 2.44 x 1.45 in0.66 lbs

Datasheet (PDF)

Open PDF
If the PDF doesnā€™t load here, click ā€œOpen PDFā€.

Features

4"x2" miniature size
Universal AC input / Full range
EMI Class B for both Class I (with FG) and Class II (without FG) configuration
No load power consumption < 0.3W
High efficiency up to 91%
Protections: Short circuit / Overload / Over voltage
Cooling by free air convection for 48W and 120W with 10CFM
Compact size
LED indicator for power on
3 years warranty
Case available

General SpecificationĀ

AC input voltage range
AC inrush current (max.) COLD START 30A/115VAC | 60A/230VAC
DC adjustment range Ā±10% rated output voltage
Overload protection Range 115%~160% rated output power
Overload protection Type Hiccup mode recovers automatically after the fault condition is removed
Over-voltage protection 110%~135% | Protection type: Shut down o/p voltage, re-power on to recover
Withstand voltage I/P-O/P: 3kVAC, I/P-FG:2kVAC, O/P-FG: 0.5kVAC, 1 minute
Working temperature -30~+70Ā°C (refer to output derating curve)
Safety standards UL62368-1, TUV BS EN/EN62368-1, IEC62368-1, approved
EMC standards EN55022 class B, EN61000-3-2,3, EN61000-4-2,3,4,5,6,8,11
Connection 3+4P/3.96mm pitch, JST B3P/B4P-VH
Dimension (LxWxH) PCB: 101.6x50.8x29 ; Case: 103.4x62x37

Similar Models

Same product family and output voltage, with the closest available power ratings.

Environmental Documents
šŸ“„ E6) COC-REACH (2026/01/28) šŸ“„ E9) CMRT (2025/04/25) šŸ“„ E14) COC-ROHS 2 (2015/863/EU) (2024/10/04) šŸ“„ REACH Certificate (PDF) (2020/12/03) šŸ“„ ROHS Certificate (PDF) (2020/05/29) šŸ“„ E12) COC-ROHS 2 (2011/65/EU) (2016/10/01)
