MDS06F-15 MEAN WELL Power Supply | HTD Electronics
Manufacturer MEAN WELL

MDS06F-15

Availability: Out of stock
6 W15 V0.4 A9V–36V in

Request a Backorder

Submit your request and we will confirm lead time.

MDS06F-15
Quantity Prices (CAD)
Quantity
Unit Price (CAD)
1+
$20.98 CAD
10+
$19.93 CAD
20+
$19.51 CAD
50+
$19.09 CAD
100+
$18.67 CAD
200+
$18.25 CAD
All prices are displayed in CAD. *Import tariff is included in the listed price. You pay exactly what you see—no surprise fees at checkout. Discounts are applied automatically based on the total quantity added to your cart.
Quick Specs
Input Voltage
9V~36V
Output Voltage
15V
Rated Current
0.4A
Power Rating
6W
Waterproof
Non-waterproof
Dimensions & Weight
1.25 x 0.79 x 0.48 in0.03 lbs

Datasheet (PDF)

Open PDF
If the PDF doesn’t load here, click “Open PDF”.

Features

DIP 24 package with international standard pinout
4:1 wide input range
Low patient leakage current <5µA
Wide operating temperature range -40~+90℃
Medical safety approved(2xMOPP) according to IEC60601-1
Protections: Short circuit(Continuous)/Overload
6KVDC or 4.2KVAC high I/O isolation(Reinforced isolation)
3 years warranty

General Specification

Voltage accuracy ±2%
Efficiency 84%
Short circuit protection Continuous, automatic recovery
Working temperature -40°C to +90°C
Temp. Coefficient 0.05% / ℃ (0 ~ 71℃)
Dimension (LxWxH) (mm) 31.8*20.3*12.2mm (1.25*0.8*0.48 inch)

Similar Models

Same product family and output voltage, with the closest available power ratings.

Environmental Documents
📄 E6) COC-REACH (2026/01/28) 📄 E9) CMRT (2025/04/25) 📄 E14) COC-ROHS 2 (2015/863/EU) (2024/10/04) 📄 REACH Certificate (PDF) (2020/12/03) 📄 ROHS Certificate (PDF) (2020/05/29) 📄 E12) COC-ROHS 2 (2011/65/EU) (2016/10/01)
